Corelink 1.25G LC 80KM SFP MODULE

Corelink 1.25G LC 80KM SFP MODULE - Detailed Description

Corelink 1.25G BIDI SFP Module 80KM LC | Tx:1490nm/Rx:1550nm & Tx:1550nm/Rx:1490nm | Single Fiber Transceiver

Upgrade your long-distance fiber network with the 1.25G Bi-Directional SFP Transceiver Module, engineered for up to 80KM point-to-point transmission over a single-mode fiber (SMF). This hot-pluggable SFP module features a single LC connector and supports WDM (Wavelength Division Multiplexing) applications, making it ideal for Gigabit Ethernet and Fiber Channel networks.

Key Features:

• 1.25Gbps bi-directional data transmission

• Wavelengths: Tx: 1490nm / Rx: 1550nm and Tx: 1550nm / Rx: 1490nm

• Reach: Up to 80 kilometers

• Connector: Single LC interface

• Fully compliant with SFP MSA specifications

• Average Output Power: -5 to -3 dBm

• Receiver Sensitivity: -22 dBm

• Low power consumption

• Metal housing for enhanced EMI shielding

• Hot-swappable for easy installation and upgrades

• Power Supply: Single 3.3V

• Operating Temperature: 0°C to 70°C

Applications:

• Gigabit Ethernet over SMF

• Fiber Channel Networks

• WDM-based communication systems

• Long-distance single fiber data links

Optimize your network performance with this cost-effective, high-performance 1.25G BIDI SFP module — perfect for ISPs, data centers, and enterprise fiber deployments.
