Senter ST805C Optical PON Power Meter
Product Specifications
- Model
- SSOPM
- Brand
- SENTER
- Category
- Network Testing Tools
- Sub Category
- Optical Power Meter
- Availability
- In Stock
Secure Payment Options:
Senter ST805C Optical PON Power Meter - Detailed Description
Senter ST805C Optical PON Power Meter Overview
The Senter ST805C Optical PON Power Meter is a compact and cost-effective testing solution for modern fiber optic networks. Designed for field and lab use, it allows technicians to measure multiple wavelengths simultaneously and analyze signal performance efficiently.
This device is widely used in FTTH, GPON, EPON, and fiber network maintenance across Bangladesh.
Key Features of Senter ST805C
1. Simultaneous testing of 1310nm, 1490nm, and 1550nm wavelengths
2. Supports APON, BPON, GPON, and EPON networks
3. Built-in threshold setting with pass/fail indication
4. Measures relative value (differential loss)
5. Data storage and upload to PC
6. User-friendly interface with large display
7. Auto power off & backlight off
8. Lightweight and portable design
9. Long battery backup (up to 18 hours)
Main Functions
1. Real-time 3 wavelength power measurement
2. Burst signal testing (1310nm upstream)
3. Threshold value configuration
4. Data storage & management
5. Battery voltage display
6. Auto shutdown for power saving
7. Real-time clock display
Specifications
|
Wavelength |
||||
|
Standard wavelengths |
1310 (upstream) |
1490 (downstream) |
1550 (downstream) |
|
|
Pass zone(nm) |
1260～1360 |
1470～1505 |
1535～1570 |
|
|
Range(dBm) |
-40～+10 |
-45～+10 |
-45～+23 |
|
|
Isolation @1310nm(dB) |
>40 |
>40 |
||
|
Isolation @1490nm(dB) |
>40 |
>40 |
||
|
Isolation @1550nm(dB) |
>40 |
>40 |
||
|
Accuracy |
||||
|
Uncertainty(dB) |
±0.5 |
|||
|
Polarization Dependent Loss (dB) |
<±0.25 |
|||
|
Linearity(dB) |
±0.1 |
|||
|
Through Insertion Loss(dB) |
<1.5 |
|||
|
Resolution |
0.01dB |
|||
|
Unit |
dBm / xW |
|||
|
General Specifications |
||||
|
Storage number |
99 items |
|||
|
Auto backlight off time |
30 30 seconds without any operation |
|||
|
Auto power off time |
10 minutes without any operation |
|||
|
Battery |
7.4V 1000mAH rechargeable Lithium battery or dry battery |
|||
|
Continuous working |
18 hours for Lithium battery; about 18 hours for dry battery too, but different for different battery brands |
|||
|
Working temperature |
-10~60℃ |
|||
|
Storage Temperature |
-25~70℃ |
|||
|
Dimension (mm) |
200*90*43 |
|||
|
Weight (g) |
About 330 |
|||
