Corelink 1x32 Steel Tube FTTH PLC Splitter

Corelink 1x32 Steel Tube FTTH PLC Splitter - Detailed Description

Corelink 1x32 FTTH PLC Splitter – Steel Tube, 1:32, 32-Way Fiber Optic Splitter

The Corelink 1x32 FTTH PLC Splitter is engineered for efficient optical signal distribution in modern fiber-to-the-home (FTTH) networks. Built with a durable steel tube design, this 32-way fiber optic splitter delivers low insertion loss, excellent signal uniformity, and high reliability, making it an ideal choice for a variety of optical communication systems.

Key Features

• Splitter Ratio: 1x32 (One input, thirty-two outputs)

• Durable Construction: High-quality steel tube for protection and compact installation

• Low Insertion Loss: Ensures efficient optical signal transmission

• Wide Wavelength Range: Supports 1260nm to 1650nm for various network types

• Stable Performance: Low polarization-dependent loss (PDL) for reliable signal quality

• Applications: Ideal for FTTH, FTTx, PON, LAN, CATV, and broadband optical networks

Technical Specifications

• Configuration: 1x32

• Operating Wavelength Range: 1260nm – 1650nm

• Insertion Loss: ≤17.0 dB

• Return Loss: ≥55 dB

• Polarization Dependent Loss (PDL): ≤0.3 dB

• Fiber Type: Single-mode G.657A1 or G.652D

• Connector Type: Bare fiber (optional SC/APC, SC/UPC, or customized)

• Fiber Length: 0.5 meter to 1 meter (standard)

• Operating Temperature: -40°C to +85°C

• Storage Temperature: -40°C to +85°C

Applications

• FTTH (Fiber to the Home) Networks

• Passive Optical Networks (PON)

• Local Area Networks (LAN)

• CATV and Broadband Distribution Systems

• FTTx Deployments and Fiber Optic Testing
