Corelink 2 Port Single Power GEPON OLT
- Model#
- CW2P1P
- Brand
- CoreLink
- Category
- FTTX Product
- Sub Category
- EPON OLT
- Warranty
- 6 Month
- Service
- 6 Month
* বর্তমানে আইটি পণ্যের দাম স্থিতিশীল না থাকায়, ওয়েবসাইটে দেয়া পণ্যের মূল্য বাড়তে পারে। *
How To Order: Over Phone, Email or Checkout in website, We Will Contact You Soon.
Corelink
2 Port Single Power GEPON OLT
is a standalone 2-PON OLT, working with all series ONU and ODN, to establish a
passive optic network. It supports 2-PON, 64 ONUs access (maximum 128). It
supports 10～20km
transmission distance at the base of high bandwidth, full line speed L2/L3
transition capacity. It supports WEB/SNMP/CLI management.
Feature
·
Supply
2 SFP PON ports, 2 1000M Combo uplink ports, 1 10/100M RJ45 management port
·
Support
SNMP management and WEB management
·
Each
PON port support 1.32 split ratio, total 64 ONUs access, maximum 128
·
Distance
can reach 20km under 1:32 split ratio, maximum 1:64
·
Support
to work with HA400/HA7200 series ONUs to establish passive network
·
1U
rack design, inside fan, better for heat dissipating and reliability operating
·
Apply
for town, village fiber network and surveillance, apply for FTTX network, to
transmit IP phone, data,IPTV and other IP services access
Application
·
1000M
point to multi-point optic passive network
Technical
Specification
|
Parameter |
Specifications |
|
Operating
wavelength |
1310（RX）/1490（TX） |
|
Optical
power |
+0 ~
+7dBm |
|
Receiving
sensitivity |
-27dBm |
|
Max
distance |
20km |
|
Max
splitter ratio |
1:64 |
|
Capacity |
2
PON, standard: 64 ONUs maximum:128 ONUs |
|
MAC |
8K |
|
Uplink
port |
2
1000M Ethernet RJ45 ports / 2 Gigabit SFP ports optional |
|
PON
port |
2
SFP fiber ports |
|
Control
port |
RJ45
console port, to debug the device |
|
MTBF |
100,000
hours |
|
EPON
trait |
Support
IEEE802.3ah |
|
Support
DBA with minimum1Kbps granularity adjustable |
|
|
Support
1Gbps up link and down link symmetrical bandwidth |
|
|
Support
AES-128 encryption to each Logical Link Identifier |
|
|
Support
powerful OAM function, implement telnet management, maintenance and upgrade |
|
|
Support
auto discovery and auto register of ONU (real-time operation) |
|
|
Protocols
supported |
Support
IEEE802.3, IEEE802.3u, IEEE802.3ab |
|
Support
IEEE802.1Q VLAN |
|
|
Support
IEEE 802.1P QoS |
|
|
Management |
CLI
and GUI, SNMP, WEB |
|
Support
DHCP Snooping |
|
|
Support
Ipv4 address learning based at DHCP Snooping |
|
|
Support
ARP Snooping, QoS etc |
Working
Environment
|
Parameter |
Specification |
|
Power
supply |
AC220V |
|
Power
consumption |
11W |
|
Operating
temperature |
-10～55℃ |
|
Storage
temperature |
-40～70℃ |
|
Humidity |
5%～90% non-condensing |
|
Dimension |
276mm(length)
×200mm(width) ×44mm(height) |
